TX26-T

Hand-held transmitters

This stylish hand-held transmitter is ideal for activating automatic garage doors, automated gates, or external lights. With a stylish design and single call button, the TX26-T includes a loop for attachment to keyrings. Compatible with any CDVI receivers using the same frequency, data transmitted is protected by KeeLoq® rolling code, giving you confidence that signals won’t be intercepted.

Key features:
1,2 or 4 channel hand-held transmitters
Ideal for triggering automatic doors and gates
Transmissions protected by KeeLoq® hopping code
Up to 150m transmission range in open field
Handy for attaching to keyrings

TECHNICAL SPECIFICATIONS:
Min Temperature (°C)
-10°C
Max Temperature (°C)
55°C
Channels
1,2 or 4
Frequency
433.92MHz
Modulation
AM/ASK
Encoding
KeeLoq® hopping code
Range in Open Field (m)
100-150m

ELECTRICAL SPECIFICATIONS:
Max Power Consumption (mA)
15mA
Battery included
3V (CR2032 Lithium battery included)

DIMENSIONS:
Product Height (mm)
72
Product Width (mm)
36
Product Depth (mm)
12
Product Weight (kg)
0.03
