Abloy EL580 Solenoid Electric Lock

Description

Abloy EL580 Solenoid Electric Lock – 50mm backset

Features:

• 50mm backset.
• For wooden or metal doors.
• With deadlocked latchbolt.
• Bolt position and handle operation.
• Outside handle controlled.
• Request to exit (RQE).
• Selection of controlled follower side.
• Easily reversible trigger bolt and deadbolt, suitable for all hands of door.
• Quick change fail locked to fail unlocked.
• Automatic deadlocking of deadbolt only when door shuts.
• Retrofits mechanical Scandinavian mortice locks.

Technical Specification:

Operating voltage +15%, -10% 12V DC to 24V DC stabilised
Current max Idle 120mA, Max 350mA
Temperature (ºC) -20 to +60
Backset (mm) 50
Follower (mm) 8
Forend finish Polished Chrome
