BO600RH

BO600RH Architectural housing, 2x300kg monitored magnets, horizontal profile

The BO600RH is a horizontal housing incorporating two 300kg monitored maglocks. Designed in the same style as our popular magnetic pull handles, the BO600RH fits across the top of the door. With the holding force of the magnets spread evenly along the length of the housing, the risk of door flexing is significantly reduced.

Because every door is different, bespoke RAL colours are available to suit the colour of the installation.

Key features:
Architectural horiziontal housing with 2x300kg monitored magnets
Fit to new doors or retrofit to existing doors
Ideal for high traffic sites that need high holding force and an aesthetic finish
Can be cut down to bespoke size and sprayed in custom RAL colour
Suitable for wooden, metal, or glass doors

TECHNICAL SPECIFICATIONS:
Fail safe
Min Temperature (°C)
-20°C
Max Temperature (°C)
70°C

ELECTRICAL SPECIFICATIONS:
Voltage AC/DC
DC
Max Power Consumption (mA)
480 @ 12Vdc / 240 @ 24Vdc

DIMENSIONS:
Product Height (mm)
925
Product Width (mm)
105
Product Depth (mm)
62
Product Weight (kg)
5.3
