DX200i Fail safe solenoid bolt, monitored

Description

DX200i
DX200i Fail safe solenoid bolt, monitored

The DX200 solenoid bolt from CDVI is an entry level fail safe locking device. With a stainless steel faceplate, retry circuit, and status monitoring, the DX200 is excellent value for securing a door. Manufactured in stainless steel, with a keeper plate of equal dimension to ensure symmetry, the DX200’s retry circuit activates if the door is not correctly aligned. Monitoring of the door position and lock position is signalled via outputs for full status of the security of the door.

Key features:
Fail safe solenoid bolt
Easy installation
Monitored door and lock status
Relock timer
Saw proof roller bolt

Technical Information:
Fail safe

ELECTRICAL SPECIFICATIONS:
Min. Voltage (V)
12Vdc
Max Voltage (V)
24Vdc
Voltage AC/DC
DC
Max Power Consumption (mA)
@12Vdc = 1000mA / @24Vdc = 500mA inrush current

LOCK DIMENSIONS:
Product Height (mm)
163
Product Width (mm)
25
Product Depth (mm)
45
Product Weight (kg)
0.44

HOUSING DIMENSIONS:
Product Height (mm)
225
Product Width (mm)
60
Product Depth (mm)
30
Product Weight (kg)
1.05
