Zoo E-Mag Door Closer Size 3

Description

E-Mag Door Closer Size 3

KEY FEATURES:

Fixed power size 3.
Aluminium.
Scissor / Steel.
Electro hold open or swing free, closing, latching speed.
60kgs (door mount pull / door mount push).
950mm (door mount pull / door mount push).
24Vdc.

Successfully tested in accordance with the requirements of BS EN 1155: 1997.
Successfully fire tested in accordance with the requirements of BS EN1634-1, suitable for use on 30, 60, 90 and 120 minute timber fire doors.
CE Marked (Certificate AE7863).
UKCA marked (Certificate AE7860).
CERTIFIRE approved (Certificate CF6104).
2-year guarantee.
Semi-radiused or Square cover.
Silver (SE) or Satin Stainless Steel (SSS) finishes available.
* Other finishes available on request.

Hold Open Mode:

Linked to the buildings Fire Detection system, Hold Open Mode can be used to safely and
legally hold open doors throughout a building to aid flow of traffic and provide barrier free
access, but upon detection of a fire, releases the door automatically allowing it to close
and prevent the spread of flames and smoke.

Swing Free Mode:

The Swing Free Electromagnetic Closer allows the door to operate as if no closer was
fitted by providing virtually no opening resistance. Linked to the buildings Fire Detection
system, the door can be positioned at any angle by the user but shuts automatically upon
first detection of a fire – preventing the spread of flames and smoke.

PRODUCT FEATURES:

• Power size: Fixed power size 3.
• Body material: Aluminium.
• Arm set type / material: Scissor / Steel.
• Functions: Electro hold open or swing free, closing, latching speed.
• Maximum door weight: 60kgs (door mount pull / door mount push).
• Maximum door width: 950mm (door mount pull / door mount push).
• Required power supply: 24Vdc.
• Performance Testing: Successfully tested in accordance with the requirements of BS EN 1155: 1997.

FIRE TESTING:

• Successfully fire tested in accordance with the requirements of BS EN1634-1, suitable for use on 30, 60, 90 and 120 minute timber fire doors.

CERTIFICATION:

• CE marked (Certificate AE7863)
• UKCA marked (Certificate AE7860)
• CERTIFIRE approved (Certificate CF6104)

GUARANTEE:

• 2-year guarantee

COVER OPTIONS:

• Semi-radiused
• Square

FINISHES:

• Silver (SE)
• Satin Stainless Steel (SSS)

SWITCH BOX FINISH:

• Silver as standard
• Black optional
• Other finishes available on request

Variation Quantity discounts available to trade:

1-9 | 10-49 | 50+
